Pmod TC1 K-Type Thermocouple
The Pmod TC1 (Revision A) is a cold-junction thermocouple-to-digital converter module designed for a K-Type thermocouple wire.
SUPPLIED_WITH : 300mm of K-type thermocouple wire with 482°C rated
• Measurement range with provided wire: -73 to +482°C
• Accuracy: ±2°C from -200 to +700°C
• Data output: 14-bit with 0.25°C resolution
• Cold-junction temperature compensation
• Host communication: serial SPI
• Follows Digilent Pmod Interface Specification Type 2
• Screw connector for thermocouple wire
• Dimensions: 25 x 20mm
Specifications
| Attribute | Value |
| Brand | Digilent |
| Kit Classification | Expansion Module |
| Kit Name | Pmod TC1: K-Type Thermocouple Module with Wire |
| Communication Protocol | SPI |
