Crouzet Current Monitoring Relay With SPDT Contacts, 1 Phase
- RS Stock No.:
- 4633654
- Mfr. Prt No.:
- 84871034
- Brand:
- Crouzet
Legislation and Compliance
RoHS Status: Not Applicable
Statement of Conformity
This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.
| RS stock number | 4633654 |
| Product description | Crouzet Current Monitoring Relay With SPDT Contacts, 1 Phase |
| Manufacturer / Brand | Crouzet |
| Manufacturer part number | 84871034 |
The foregoing information relates to product sold on, or after, the date shown below.
RS COMPONENTS
| Date | Dec 25, 2024 |
RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132
Country of Origin: FR
Product Details
Current Control Relays – EI
Note
2 to 500mA (EIL), 0.1 to 10A (EIH) and 10 to 100A (EIT with CT) measurement ranges
Current transformer available for use with EIT control relays; stock no 283-6384
Threshold and hysteresis separately adjustable
Selection of over-current or under-current by means of a dip switch
(Operating range quoted is relative to nominal supply voltage (Un) )
Specifications
| Attribute | Value |
| Brand | Crouzet |
| Height | 99.3 mm |
| Monitoring Application | Current |
| Maximum Current Sensed | 10 A |
| Dimensions | 100 x 22.5 x 99.3 mm |
| Length | 100 mm |
| Minimum Current Sensed | 0.1 A |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -20 °C |
| Width | 22.5 mm |
| Time Delay | 0.1 → 3 s |
| Maximum Operating Temperature | +60 °C |
| Electrical Phase | 1 |
| Current Range | 0.1 mA → 10 A |
| Operating Temperature Range | -20 → +60 °C |
| Current Sensitivity | Overcurrent, Undercurrent |
